MONOBOLT® 9.5mm (10mm) [3/8] Aluminum / Aluminum Structural Rivet Nuts - 02774-01228
Cód:
02774-01228
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

3.05-15.88 mm grip with 9.5mm (10mm) [3/8] Nominal Diameter based on Dome Head Style with Aluminum Body material and Aluminum Mandrel material

Monobolt

product name3.048-15.875 mm Aluminum/Aluminum Monobolt Structural Blind Rivets
Body MaterialAluminium
Mandrel MaterialAluminium
Finish-BodyPolished
Finish- MandrelNatural
Head StyleDome
Min grip mm3.04
Max grip mm15.87
Min Grip Inches0.12
Max Grip Inches0.625
Min Hole Size mm9.95
Max Hole Size mm10.4
Min Holes Size Inches0.392
Max Hole Size Inches0.409
Max Body Length mm21.5
Max Body Length Inches0.846
Max Secondary Protrusion mm36.2
Max Secondary Protrusion inches1.425
Flange Diameter mm20.3
Flange Diameter inches0.798
Flange Thickness mm4.1
Flange Thickness Inches0.144
Shear kN12.63
Tensile kN9.3
Shear lbf2840.0
Tensile lbf2092.0
BrandAvdel
Nominal Diameter10mm [3/8]
Max Secondary Protrusion Inches1.425

default

JDE_HTS_Code8308206000
JDE_Country_of_OriginGB
JDE_Lead_Time_Days168
Minimum Order Quantity30000
Features

    Fast Facts:

  • Structural breakstem rivet.
  • Stem mechanically locked into body.
  • Blind hole, one-sided installation capability.
  • Multi-grip capability.
  • High shear and tensile strength.
  • Good sheet take-up performance.
  • Visible lock for quick and easy inspection.
  • Excellent hole fill via rapidly expanded body.
  • Wide choice of installation tools.
  • One fastener can be used to replace several standard grip fasteners.
  • Reduced fastener inventory and simpler stock control.
  • Compensates for irregular, oversized, slotted or misaligned holes.
  • Can stop sheet movement in non-standard holes.
  • Large gap closing capability.
  • Provides very strong, vibration resistant joints.
  • No damage, electrical problems, or rattling due to loose stems.
  • Breakstem fasteners can be customized to meet unique assembly requirements.

    • Specifications:
  • Sizes: 4.8mm, 6.4mm and 10 mm (3/16", ¼" and 3/8")
  • Materials: Aluminum alloy, steel and stainless steel 304 grade / A2 and 316 grade / A4
  • Headforms: Protruding and countersunk
