MONOBOLT® 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts - 02761-00821

Cód:

02761-00821

Opinião dos Consumidores:0

De: $0.00Por: $0.02ou 1X de $0.02

Preço a vista: $0.02

Comprar

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto Especificações do Produto Avaliações

Descrição do Produto

3.18-12.07 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Countersunk Head Style with Steel Body material and Steel Mandrel material

Monobolt

product name	3.175-12.065 mm Steel/Steel Monobolt Structural Blind Rivets
Body Material	Steel
Mandrel Material	Steel
Finish-Body	Zinc Plate
Finish- Mandrel	Zinc Plate
Head Style	Countersunk
Min grip mm	3.17
Max grip mm	12.07
Min Grip Inches	0.125
Max Grip Inches	0.475
Min Hole Size mm	6.6
Max Hole Size mm	7.0
Min Holes Size Inches	0.25984
Max Hole Size Inches	0.275
Max Secondary Protrusion mm	26.4
Max Secondary Protrusion inches	1.037
Flange Diameter mm	10.1
Flange Thickness mm	2.4
Flange Thickness Inches	0.093
Shear kN	11.78
Tensile kN	10.45
Shear lbf	2650.0
Tensile lbf	2350.0
Brand	Avdel
Nominal Diameter	6.4mm [1/4]
Max Secondary Protrusion Inches	1.037

default

Minimum Order Quantity 1500

Features

Minimum Order Quantity	1500
Features	Fast Facts: Structural breakstem rivet. Stem mechanically locked into body. Blind hole, one-sided installation capability. Multi-grip capability. High shear and tensile strength. Good sheet take-up performance. Visible lock for quick and easy inspection. Excellent hole fill via rapidly expanded body. Wide choice of installation tools. One fastener can be used to replace several standard grip fasteners. Reduced fastener inventory and simpler stock control. Compensates for irregular, oversized, slotted or misaligned holes. Can stop sheet movement in non-standard holes. Large gap closing capability. Provides very strong, vibration resistant joints. No damage, electrical problems, or rattling due to loose stems. Breakstem fasteners can be customized to meet unique assembly requirements. Specifications: Sizes: 4.8mm, 6.4mm and 10 mm (3/16", ¼" and 3/8") Materials: Aluminum alloy, steel and stainless steel 304 grade / A2 and 316 grade / A4 Headforms: Protruding and countersunk

Fast Facts:

Structural breakstem rivet.
Stem mechanically locked into body.
Blind hole, one-sided installation capability.
Multi-grip capability.
High shear and tensile strength.
Good sheet take-up performance.
Visible lock for quick and easy inspection.
Excellent hole fill via rapidly expanded body.
Wide choice of installation tools.
One fastener can be used to replace several standard grip fasteners.
Reduced fastener inventory and simpler stock control.
Compensates for irregular, oversized, slotted or misaligned holes.
Can stop sheet movement in non-standard holes.
Large gap closing capability.
Provides very strong, vibration resistant joints.
No damage, electrical problems, or rattling due to loose stems.
Breakstem fasteners can be customized to meet unique assembly requirements.

Specifications:
Sizes: 4.8mm, 6.4mm and 10 mm (3/16", ¼" and 3/8")
Materials: Aluminum alloy, steel and stainless steel 304 grade / A2 and 316 grade / A4
Headforms: Protruding and countersunk
