MONOBOLT® 4.8mm [3/16] (6) Aluminum / Aluminum Structural Rivet Nuts - 02764-00615

Cód:

02764-00615

Opinião dos Consumidores:0

Avdel

MONOBOLT® 4.8mm [3/16] (6) Aluminum / Aluminum Structural Rivet Nuts - 02764-00615

Cód:

02764-00615

Opinião dos Consumidores:0

De: $0.00Por: $0.02ou 1X de $0.02

Preço a vista: $0.02

Comprar

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto Especificações do Produto Avaliações

Descrição do Produto

3.18-8.41 mm grip with 4.8mm [3/16] (6) Nominal Diameter based on Countersunk Head Style with Aluminum Body material and Aluminum Mandrel material

Monobolt

product name	3.175-8.4074 mm Aluminum/Aluminum Monobolt Structural Blind Rivets
Min Holes Size Inches	0.193
Max Hole Size Inches	0.2
Max Body Length mm	12.75
Max Body Length Inches	0.501
Max Secondary Protrusion mm	20.0
Max Secondary Protrusion inches	0.786
Flange Diameter mm	8.3
Flange Thickness mm	2.2
Flange Thickness Inches	0.084
Shear kN	2.89
Tensile kN	2.11
Shear lbf	650.0
Tensile lbf	475.0
Brand	Avdel
Nominal Diameter	4.8mm [3/16]
Max Secondary Protrusion Inches	0.786
Max Hole Size mm	5.1
Min Hole Size mm	4.9
Max Grip Inches	0.331
Min Grip Inches	0.125
Max grip mm	8.41
Min grip mm	3.17
Head Style	Countersunk
Finish- Mandrel	Natural
Finish-Body	Polished
Mandrel Material	Aluminium
Body Material	Aluminium

default

Minimum Order Quantity 4000

Features

Minimum Order Quantity	4000
Features	Fast Facts: Structural breakstem rivet. Stem mechanically locked into body. Blind hole, one-sided installation capability. Multi-grip capability. High shear and tensile strength. Good sheet take-up performance. Visible lock for quick and easy inspection. Excellent hole fill via rapidly expanded body. Wide choice of installation tools. One fastener can be used to replace several standard grip fasteners. Reduced fastener inventory and simpler stock control. Compensates for irregular, oversized, slotted or misaligned holes. Can stop sheet movement in non-standard holes. Large gap closing capability. Provides very strong, vibration resistant joints. No damage, electrical problems, or rattling due to loose stems. Breakstem fasteners can be customized to meet unique assembly requirements. Specifications: Sizes: 4.8mm, 6.4mm and 10 mm (3/16", ¼" and 3/8") Materials: Aluminum alloy, steel and stainless steel 304 grade / A2 and 316 grade / A4 Headforms: Protruding and countersunk

Fast Facts:

Structural breakstem rivet.
Stem mechanically locked into body.
Blind hole, one-sided installation capability.
Multi-grip capability.
High shear and tensile strength.
Good sheet take-up performance.
Visible lock for quick and easy inspection.
Excellent hole fill via rapidly expanded body.
Wide choice of installation tools.
One fastener can be used to replace several standard grip fasteners.
Reduced fastener inventory and simpler stock control.
Compensates for irregular, oversized, slotted or misaligned holes.
Can stop sheet movement in non-standard holes.
Large gap closing capability.
Provides very strong, vibration resistant joints.
No damage, electrical problems, or rattling due to loose stems.
Breakstem fasteners can be customized to meet unique assembly requirements.

Specifications:
Sizes: 4.8mm, 6.4mm and 10 mm (3/16", ¼" and 3/8")
Materials: Aluminum alloy, steel and stainless steel 304 grade / A2 and 316 grade / A4
Headforms: Protruding and countersunk
