MONOBOLT® 6.4mm [1/4] (8) Stainless Steel / Stainless Steel Structural Rivet Nuts - 02721-00821
Cód:
02721-00821
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

3.17-12.07 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Countersunk Head Style with Stainless Steel Body material and Stainless Steel Mandrel material

Monobolt

product name3.17-12.07 mm Stainless Steel/Stainless Steel Monobolt Structural Blind Rivets
Body MaterialStainless Steel
Mandrel MaterialStainless Steel
Finish-BodyNatural
Finish- MandrelNatural
Head StyleCountersunk
Min grip mm3.17
Max grip mm12.07
Min Grip Inches0.124
Max Grip Inches306.578
Min Hole Size mm6.6
Max Hole Size mm7.0
Min Holes Size Inches0.259
Max Hole Size Inches0.275
Max Secondary Protrusion mm26.4
Max Secondary Protrusion inches1.037
Flange Diameter mm10.05
Flange Diameter inches0.016
Flange Thickness mm2.4
Flange Thickness Inches0.093
Shear kN11.78
Tensile kN10.45
BrandAvdel
Nominal Diameter6.4mm [1/4]
Max Secondary Protrusion Inches1.037

default

JDE_Weight_UOMLB
JDE_Weight_Per_UOMM
JDE_HTS_Code8308206000
JDE_Country_of_OriginGB
JDE_Lead_Time_Days252
JDE_Weight26.52161
Minimum Order Quantity1500
Features

    Fast Facts:

  • Structural breakstem rivet.
  • Stem mechanically locked into body.
  • Blind hole, one-sided installation capability.
  • Multi-grip capability.
  • High shear and tensile strength.
  • Good sheet take-up performance.
  • Visible lock for quick and easy inspection.
  • Excellent hole fill via rapidly expanded body.
  • Wide choice of installation tools.
  • One fastener can be used to replace several standard grip fasteners.
  • Reduced fastener inventory and simpler stock control.
  • Compensates for irregular, oversized, slotted or misaligned holes.
  • Can stop sheet movement in non-standard holes.
  • Large gap closing capability.
  • Provides very strong, vibration resistant joints.
  • No damage, electrical problems, or rattling due to loose stems.
  • Breakstem fasteners can be customized to meet unique assembly requirements.

    • Specifications:
  • Sizes: 4.8mm, 6.4mm and 10 mm (3/16", ¼" and 3/8")
  • Materials: Aluminum alloy, steel and stainless steel 304 grade / A2 and 316 grade / A4
  • Headforms: Protruding and countersunk
