AVDEL Carbon steel Lockbolts with 6.4mm [1/4] nominal diameter with 7.16 - 8.76 mm grip range - 21021-00805
Cód:
21021-00805
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

7.16-8.76 mm grip with 6.4mm [1/4] Nominal Diameter based on Collar head style and Carbon steel Pin Material

Avbolt

nominal Diameter6.4mm [1/4]
Pin MaterialCarbon steel
Head StyleCollar
Min grip mm7.16
Max grip mm8.76
Min Grip Inches0.282
Max Grip Inches0.345
Min Hole Size mm7.04
Max Hole Size mm7.42
Min Holes Size Inches0.277
Max Hole Size Inches0.292
Body Length mm21.29
Body Length Inches0.838
Head Diameter mm9.7
Head Diameter inches0.382
Head Thickness mm6.6
Head Thickness Inches0.26

default

JDE_Lead_Time_Days112
Minimum Order Quantity10000
Features

    Fast Facts:

  • Use on blind-sided application.
  • High tensile and shear strength.
  • Speed of installation.
  • Vibration resistance.
  • High grip capability.
  • Tamper resistant.
  • Ideal for areas with restricted access.
  • Used in assembly applications such as ship building, railway, automotive assembly including car seats, other ground transportation, mining equipment, and construction.

    • Specifications:
  • Sizes: 4.8 mm, 6.4 mm, 8.0 mm, 10 mm, 12.7 mm and 1 6mm (3/16", 1/4'', 1/2", 5/16", 3/8" and 5/8")
  • Materials Stem: Alloy steel, black oxide
  • Materials Sleeve and collar: Carbon steel, zinc plated + clear passivated
  • Collar: Flanged (only on 3/8'', 1/2" & 5/8'' (three piece) diameters)
