Interlock 4.8mm [3/16] (6) Aluminum / Aluminum Structural Rivet Nuts - BAPI-06-07
Cód:
BAPI-06-07
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

5.44-11.1 mm grip with 4.8mm [3/16] (6) Nominal Diameter based on Protruding Head Head Style with Aluminum Body material and Aluminum Mandrel material

Interlock

product name5.4356-11.0998 mm Aluminum/Aluminum Interlock Structural Blind Rivets
nominal Diameter4.8mm [3/16] (6)
Body MaterialAluminium
Mandrel MaterialAluminium
Finish-BodyNone
Finish- MandrelNone
Head StyleProtruding Head
Min grip mm5.44
Max grip mm11.1
Min Grip Inches0.214
Max Grip Inches0.437
Min Hole Size mm4.93
Max Hole Size mm5.18
Min Holes Size Inches0.194
Max Hole Size Inches0.204
Max Secondary Protrusion mm22.25
Max Secondary Protrusion inches0.875
Flange Diameter mm10.2
Flange Diameter inches0.4
Flange Thickness mm2.29
Flange Thickness Inches0.09
Shear kN2.66
Tensile kN2.0
Shear lbf600.0
Tensile lbf450.0
BrandAvdel
Nominal Diameter4.8mm [3/16]
Max Secondary Protrusion Inches0.875

default

JDE_Weight_UOMLB
JDE_Weight_Per_UOMM
JDE_HTS_Code8308206000
JDE_Country_of_OriginUS
JDE_Lead_Time_Days98
JDE_Weight3.498
Features

    1. Excellent hole fill via radially expanded body provides greater joint integrity, added water resistance and compensates for irregular, oversized, slotted or misaligned holes

  • 2. Can stop sheet movement in non-standard holes
  • 3. Good sheet take-up performance for large gap closing capability
