Interlock 6.4mm [1/4] (8) Aluminum / Aluminum Structural Rivet Nuts - BAPI-08-06
Cód:
BAPI-08-06
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

2.03-9.53 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Protruding Head Head Style with Aluminum Body material and Aluminum Mandrel material

Interlock

product name2.032-9.525 mm Aluminum/Aluminum Interlock Structural Blind Rivets
nominal Diameter6.4mm [1/4] (8)
Body MaterialAluminium
Mandrel MaterialAluminium
Finish-BodyNone
Finish- MandrelNone
Head StyleProtruding Head
Min grip mm2.03
Max grip mm9.53
Min Grip Inches0.08
Max Grip Inches0.375
Min Hole Size mm6.63
Max Hole Size mm7.01
Min Holes Size Inches0.261
Max Hole Size Inches0.276
Max Secondary Protrusion mm27.7
Max Secondary Protrusion inches1.181
Flange Diameter mm13.5
Flange Diameter inches0.53
Flange Thickness mm2.97
Flange Thickness Inches0.117
Shear kN5.78
Tensile kN3.69
Shear lbf1300.0
Tensile lbf830.0
BrandAvdel
Nominal Diameter6.4mm [1/4]
Max Secondary Protrusion Inches1.181

default

JDE_Weight_UOMLB
JDE_Weight_Per_UOMM
JDE_HTS_Code8308206000
JDE_Country_of_OriginUS
JDE_Lead_Time_Days56
JDE_Weight7.039
Minimum Order Quantity3000
Features

    1. Excellent hole fill via radially expanded body provides greater joint integrity, added water resistance and compensates for irregular, oversized, slotted or misaligned holes

  • 2. Can stop sheet movement in non-standard holes
  • 3. Good sheet take-up performance for large gap closing capability
