AVDEL Carbon Boron Steel Lockbolts with 6.4mm [1/4] (8) nominal diameter with 1.57 - 4.75 mm grip range - 02621-70802
Cód:
02621-70802
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

1.57-4.75 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Brazier Head head style and Carbon Boron Steel Pin Material

Avdelok

Body Length mm0.0
Flanged Collar Part No.02615-70800
Half Collar Part No.02682-70800
Full Collar Part No.02662-70800
Tensile lbf3000.0
Shear lbf3310.0
Tensile kN13.35
Shear kN14.73
Head Thickness Inches0.161
Head Thickness mm4.1
Head Diameter inches0.526
Head Diameter mm13.4
Max Hole Size Inches0.261
Min Holes Size Inches6.6
Max Hole Size mm0.26
Min Hole Size mm6.6
Max Grip Inches0.187
Min Grip Inches0.62
Max grip mm4.75
Min grip mm1.57
Head StyleBrazier Head
Pin MaterialCarbon Boron Steel
nominal Diameter6.4mm [1/4] (8)

default

JDE_HTS_Code7318290000
JDE_Country_of_OriginTW
JDE_Lead_Time_Days252
Minimum Order Quantity14000
Features

    Fast Facts:

  • High-strength, high-speed assembly.
  • High shear and tensile strength.
  • Excellent vibration resistance.
  • Consistent, high performance.
  • TIR approved – easy to inspect for tampering.
  • Robust and rugged installation tools.
  • Fasten metal to metal.
  • Used in construction, bridge building, commercial vehicles, fencing, mining, railways, and reefer cool and dry freight containers.

    • Specifications:
  • Sizes: 4.8mm to 9.6mm (3/16" to 3/8")
  • Materials: Aluminum alloy, steel, and stainless steel
  • Headforms: Brazier, countersunk, truss, and large head
  • Collars: Full, half, and flanged
