0.5 - 7.1 mm Steel Versanut Rivet Nuts - 0VN21-02634

Cód:

0VN21-02634

Opinião dos Consumidores:0

De: $0.00Por: $0.02ou 1X de $0.02

Preço a vista: $0.02

Comprar

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto Especificações do Produto Avaliações

Descrição do Produto

Versanut Steel 0.5 - 7.1 mm Large Flange Slotted Rivet Nuts

Versanut

Description	0.5 - 7.1 mm Large Flange Slotted Steel Versanut Rivet Nuts
Product family	Versanut
Material	Steel
Open / Closed	Open
Head Style	Large Flange
Body Style	Slotted
Thread	M6
Min grip mm	0.5
Max grip mm	7.1
Min Hole Size mm	8.8
Max Hole Size mm	8.93
Max Body Length mm	27.3
Max Flange Diameter mm	16.12
Max Flange Thickness mm	1.63

default

Minimum Order Quantity 1000

Features

Minimum Order Quantity	1000
Features	Fast Facts: Installed quickly by using simple handtools (less than 3 seconds). Blind hole, one-sided installation capability. Extra-large blind side bearing area after placing. Higher pull out and torque-to-turn resistance. Less radial loading of holes in brittle materials. Less risk of cracking and de-lamination of composites. Up to twice the grip range of standard blind inserts. Enables a designer to reduce the size or number of fasteners in an assembly. Covers large variations of thicknesses. Assembly applications include automotive trim and moldings, truck and trailer sandwich sections and paneling, domestic appliances (handles, adjustable feet, and fixing points) and plastic fabrications (assembly of plastic recreation equipment). Specifications: Sizes: M5 – M8 Material: Low carbon steel Headform: Large flange

Fast Facts:

Installed quickly by using simple handtools (less than 3 seconds).
Blind hole, one-sided installation capability.
Extra-large blind side bearing area after placing.
Higher pull out and torque-to-turn resistance.
Less radial loading of holes in brittle materials.
Less risk of cracking and de-lamination of composites.
Up to twice the grip range of standard blind inserts.
Enables a designer to reduce the size or number of fasteners in an assembly.
Covers large variations of thicknesses.
Assembly applications include automotive trim and moldings, truck and trailer sandwich sections and paneling, domestic appliances (handles, adjustable feet, and fixing points) and plastic fabrications (assembly of plastic recreation equipment).
Specifications:
Sizes: M5 – M8
Material: Low carbon steel
Headform: Large flange
