Avibulb XT 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts - 0BN01-00816
Cód:
0BN01-00816
Opinião dos Consumidores:0

Por: $0.02

Preço a vista: $0.02

Calcule o valor do frete e prazo de entrega para a sua região

Descrição do Produto

1.5-5.5 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material

Avibulb XT

product name1.5-5.5 mm Steel/Steel Avibulb XT Structural Blind Rivets
nominal Diameter6.4mm [1/4] (8)
Body MaterialSteel
Mandrel MaterialSteel
Finish-BodyZinc Plate
Finish- MandrelZinc Plate
Head StyleDome
Min grip mm1.5
Max grip mm5.5
Min Grip Inches0.59
Max Grip Inches0.27
Min Hole Size mm6.6
Max Hole Size mm7.0
Min Holes Size Inches0.259
Max Hole Size Inches0.275
Max Body Length mm13.0
Max Body Length Inches0.512
Max Secondary Protrusion mm17.3
Max Secondary Protrusion inches0.6811
Flange Diameter mm13.4
Flange Diameter inches0.528
Flange Thickness mm3.1
Flange Thickness Inches0.122
Shear kN11.1
Tensile kN6.8
BrandAvdel
Nominal Diameter6.4mm [1/4]
Max Secondary Protrusion Inches0.681
Shear lbf2495.0
Tensile lbf1528.0

default

JDE_Weight_UOMLB
JDE_Weight_Per_UOMM
JDE_HTS_Code8308206000
JDE_Country_of_OriginGB
JDE_Lead_Time_Days252
JDE_Weight22.20055
Minimum Order Quantity1000
Features

    Fast Facts:

  • Structural breakstem rivet.
  • Reliable stem retention.
  • Blind hole, one-sided installation capability.
  • High shear and tensile strength.
  • Multi-grip capability.
  • High residual clamp load.
  • Resists vibration and joint slippage.
  • Good blind side footprint and bulb formation.
  • Spreads the tail bearing load/clamp on the rear sheet.
  • Suitable in softer materials.
  • Under head recess accommodates burrs around holes and spreads load evenly on top sheet.
  • Avdel® patent protected.
  • Breakstem fasteners can be customized to meet unique assembly requirements.


    • Specifications:
  • Size: 6.4mm (1/4'') diameter
  • Material: Steel, zinc & clear passivated
  • Headform: Dome
